Three-dimensional motion mixer is a kind of mixer, which is not only suitable for the mixing of general materials in various industries, but also suitable for the mixing of materials containing more oil, more sugar, high viscosity, flammable, explosive, temperature curing, temperature softening. The three-dimensional motion mixer is different from the traditional rotary mixer, the three-dimensional motion mixer makes "translation, rotation, rock movement on the three-dimensional space of the cube, so that the material in the mixing cylinder is in" rotating flow, translation. TURBULA: A complicated movement known as turbula:
Before using the three-dimensional motion mixer, an empty running test should be carried out. Before the test, the tightness of all the connecting parts of the machine, the amount of lubricating oil of the reducer and the integrity of the motor equipment should be checked, and then the main power switch should be closed for empty running test. Click the round material and reset button respectively, check whether the working condition is good, and process after meeting the above requirements (the filling button and the reset button cannot be used at the same time). After feeding, it is necessary to cover the cover of the tank to avoid shallow discharge of the material. The cover is an organic glass to observe the mixing of the material. If the mixing achieves the effect, click the pour button to pour the material, and stop when the hopper is close to the frame to prevent broken parts.
In the operation of the three-dimensional motion mixer, due to the multi-direction operation of the mixing barrel, the flow and diffusion of various materials are accelerated during the mixing process, while avoiding the specific gravity segregation and accumulation of the material caused by the centrifugal force of the general mixer, "mixing" can effectively ensure the best quality of the mixed materials.
The general mixer has only one power mechanism, only one or two mixing methods, the three-dimensional mixer uses three sets of power mechanism, with radial tipping, axial flipping, axial mixing, side mixing and other mixing methods at the same time, can add frequency converter, speed regulation motor.
Reasonable structure, inflatable sealing drive shaft, can be switched to water when cleaning, fluidized granulation, granulation approximate ball line, good fluidity. Compared with the traditional process, the adhesive is reduced by 25%, the drying time is shortened, the dry mixing is 2 minutes each time, the granulation is 1-4 minutes, and the efficiency is 4.5 times higher than that of the traditional process.
