Disc Mill

What is Disc Mill?

A disc mill is a type of crusher that can be used to grind, cut, shear, shred, fiberize, pulverize, granulate, crack, rub, curl, fluff, twist, hull, blend, or refine. It works in a similar manner to the ancient Buhrstone mill in that the feedstock is fed between opposing discs or plates. The discs may be grooved, serrated, or spiked.

Advantages of Disc Mill

High capacity

Four inlet valves to mix and grind your seeds at the same time.Capacity varies from 1,000 to 12,000 kg/h for wheat.Optimal mill capacity ensured through Augers frequency control system.

Low power consumption

Powerfull electric engine.Typically only 5kWh per ground tonne,ensuring optimal cost reduction over the life of your equipment.

Durability

Each set of discs can grind 10,000 – 25,000 tonnes of grain until spare parts are needed, dependent on size of mill.Disc mills active components have been tested to be nearly 3x as hard as a traditional hammer mills ensuring a long life.

Low noise

Powerfull electric motor.Noise level similar to an alarm clock ringing, compared to a traditional mill being a petrol lawn mower.

First 12 3 Last 1/3

Why Choose Us

Factory

Our company covers an area of 15,000km2, including a building area of 6,000km2. We have more than 100 employees.

24h online service

We are happy to help our customers at any time as we have dedicated and hardworking service back end team working 24 hours.

Rich technical experience

Our staff are some of the most experienced in the industry, providing product-correct advice and solutions, ensuring we provide our customers with technical expertise and service.

Universal Coarse Crusher For Medicinal Herbs

Strict quality control

All machines undergo rigorous quality control at the factory to ensure that the quality of the machines we supply meets one of the highest standards.

Types of Disc Mill

Single-disc mill:

Single disc mills are available in sizes 24" to 52" for use with motors ranging from 25 HP to 1000 HP. Hand wheel plate gap adjustment (standard), with optional motor controlled adjustments available on some models,V-belt drive with overhead-motor mounts. (1000 HP unit is floor mounted only),Front swing door plate access,Packing-gland shaft seals,Cast and fabricated construction,Quick-release plate unloading,Gravity or mechanical feed,Available in carbon or stainless steel

Double-disc mills:

Double disc mills are available in sizes 24" to 36" for use with motors ranging from 200 HP to 500 HP. The double-disc/double-motor arrangement allows the applied horsepower to be divided to each end of the mill, affording higher throughput at greater HP.Available in carbon or stainless steel,V-belt drive with optional overhead or floor motor mounts,Sliding bearing plate gap adjustment,Spring-loaded packing seals,Quick-release plate unloading.

Methods to Reduce Wear on Disc Mill

Excessive wear will lead to poor grinding effect and increase the use cost of disc grinding, so we try to reduce the wear of grinding balls in use.The problem of damage to the grinding chamber of the disc grinder is not to let the user reduce the number of times of use, but to pay attention to several factors in daily use, then the damage to the disc grinder can be avoided.

First of all, in terms of the size, ratio and loading capacity of the disc mill, the quality of the disc mill will change with the size. At a certain speed of the ball mill, the greater the quality of the grinding ball, the greater the impact. When configuring the size of the grinding balls, the collision probability between the grinding balls of the same size is higher, and the grinding balls are prone to fatigue wear, and the loading of the grinding balls will also affect the collision probability between the grinding balls.

The production efficiency of the disc grinder is low. The main factor affecting its production efficiency is that the rotation rate of the driving shaft is too low, which leads to relatively serious wear and tear caused by insufficient power. If the distance between the grinding discs is too small, it will affect the flow. If this happens, we should increase the distance as much as possible within the scope.

Then consider the properties of the material to be ground by the disc mill. The hardness, brittleness, shape and size of the material have an extremely important influence on the grinding process of the grinding chamber.

Working Principle of Disc Mill

The feed material enters the dustproof chamber from the filling hopper and is fed centrally between two vertical grinding discs. A moving grinding disc rotates against a fixed one and draws in the feed material. The necessary comminution effects are generated by pressure and frictional forces. The progressively arranged grinding disc meshing first subjects the sample to preliminary crushing; centrifugal force then moves it to the outer regions of the grinding discs where fine comminution takes place. The processed sample exits through the grinding gap and is collected in a receiver. The gap width between the grinding discs is continuously adjustable and can be adjusted during operation in the range between 0.1 and 5 mm; an additional observation window is provided for checking the gap setting.

Disc Mill Machine Structure

It adopts hydraulic transmission, has simple structure and easy operation. The main shaft is supported on two fulcrums. While the moving plate rotates, its axial direction bears the working pressure of the hydraulic drive. Hydraulic oil has strong elasticity. As the pressure of the material to be ground changes, the gap between the moving and fixed plates also changes slightly, which facilitates the separation of fibers.

The gap of the fixed plate can be adjusted, and the gap adjustment of the fixed plate is realized through the guide valve of the hydraulic system. The gap size is displayed by an electric indicator, which is convenient and accurate. When the pilot valve fails, the handwheel, worm gear and other mechanisms can also be used to realize the intermittent adjustment of the moving and fixed plates.

The water seal and water cooling system can take away the heat generated in the grinding chamber in time to prevent the deformation of the wear-resistant sleeve, high temperature of the bearing oil and burning of the packing. The function of the water seal device is to prevent the pulp in the grinding chamber from entering the side of the front bearing.

Set up an electro-hydraulic interlocking protection system that interlocks the oil pump motor and the main motor, seals the water pressure micro switch and the main motor, the lubricating oil micro switch and the main motor, and the lubricating oil temperature micro switch and the main motor. To ensure the normal operation of the disc mill.

Certifications

With rich experiences and consistent quality,kept qualifying the Chinese Enterprise with "AAA" credit rating and contract compliance, passed ISO9002 in 2003 got CE certificated in 2010, always led the powder and granules equipment market with dozens of patents.

202310161329403de0bbfa22bf4ffb959228028455554d

20231016133027240a79082f394dd18cd04547b7117764

2023101613295571696040792140a1ae31969a474e6f94

20231016133003255085987b2440c78f7e9be7dda125ad

202310161329595545e804d73248c5ae1c04561b9724e6

20231016133031fc44a3b3c06a4df3a91e1046fcb5cd53

Our Factory

Our company covers an area of 15,000km2, including a building area of 6,000km2. We have more than 100 employees.

FAQ

Q: What is the working principle of disk mill?

A: The product is drawn through the grinding disk by centrifugal forces, whereby the static grinding disk is attached to the lid (stator) and the rapidly rotating disk is located below in the grinding housing.

Q: What are the advantages of disk mill?

A: The disc mills are suitable for grinding of many different types of raw materials, including pellets with a diameter up to 12 mm. One of the advantages of the mill disc is that it is possible to vary the degree of grinding during operation, and then optimize the structure to feed different groups of animals.

Q: What is the mechanism of disk mill?

A: The material is ground by pressure and shearing action between two counteracting grinding disks with coarse interlocking teeth. The ground material automatically falls down through a pre-set grinding gap into the collection drawer.

Q: What is the difference between a roller mill and a disc mill?

A: The higher the speed, the shorter the grinding time and the finer the grist, but the higher the energy consumption. Regardless of the speed used, the disc mill has a higher energy consumption than a two-roll mill, but the grinding time is shorter and the malt finer.

Q: What is the capacity of a disc mill?

A: Disc mills are one average 10% more efficient in power consumption than hammer mills and can achieve a capacity of about 6 tons/hour. Machines with capacities of up to 24 tons/hour are available upon request.

Q: What is a disc mill used for?

A: A disc mill is a type of crusher that can be used to grind, cut, shear, shred, fiberize, pulverize, granulate, crack, rub, curl, fluff, twist, hull, blend, or refine.

Q: How does a disc attrition mill work?

A: In attrition milling, an abrasive rubbing action presses the materials between two counter-rotating, metal discs. Materials enter from the infeed into the center of the discs and centrifugal force directs them outward and ultimately through the discs to discharge, ground into the desired particle size.

Q: What is disc mill pulverizer?

A: This type of pulverizer is most commonly known as a Disk Pulverizer or a Disk Mill and can be used for intermittent and continuous fine grinding of hard-brittle and medium-hard materials in the field of mining and metallurgy, glass industry, ceramics industry. Ideal for preparing samples before assaying them.

Q: What are the two types of mills?

A: The two basic forms of milling are dry milling and wet milling where dry milling uses particle to particle contact while wet milling suspends materials in a slurry. There are numerous types of mills, and materials processed by them.

Q: What is the application of disc mill in food industry?

A: PUC perforated disc mills are used for crushing lumpy solid pieces and for mashing materials such as fruit, vegetables and meat, for the pre-comminution of soy beans and in general for the production and processing of foodstuffs, chemical and cosmetic products and the comminution of soaked paper.

Q: What can a mill be used for?

A: A mill is a device, often a structure, machine or kitchen appliance, that breaks solid materials into smaller pieces by grinding, crushing, or cutting. Such comminution is an important unit operation in many processes. There are many different types of mills and many types of materials processed in them.

Q: What is the difference between a grinder and a disc cutter?

A: What is the Difference Between an Angle Grinder and a Disc Cutter? The versatile, durable angle grinder is suitable for applications such as cutting, grinding, polishing and sharpening. Conversely, the disc cutter is a small, single-handed cutting blade which is best suited to light cutting applications.

Q: Can you grind with cutting disc?

A: NO! Cutting-off wheels are for cutting on the periphery ONLY. Why? Cutting-off wheels are thin by design and do not have adequate lateral strength for side grinding.

Q: Can a metal cutting disc cut concrete?

A: In some way,you could cut concrete with a metal cutting disc. But you'll find that there's a drastic difference in the performance. Because a concretecutting disc has a silicon-carbide abrasive. Whereas a metal cutting disc will have either zirconia or aluminum oxide, depending on their going to be used for.

Q: Do grinding discs expire?

A: The reason that cutting and grinding discs have a shelf life is that the resin that is used to bind the disc material together breaks down over time as it absorbs moisture from the atmosphere. This means that an out of date disc could break up during use, with sharp fragments being ejected at a very high speed.

Q: What are the 4 types of grinding machine?

A: Grinding machines fall into five categories: surface grinders, cylindrical grinders, centerless grinders, internal grinders and specials. Surface grinders are used to produce flat, angular and irregular surfaces.

Q: Why do grinder discs break?

A: Improper Machine Conditions. Loose wheel spindle, excessive end play, and loose or vibrating machine parts such as the work-table and the work holder may cause the wheel to bend in the cut and break.

Q: What is the purpose of a roller mill?

A: Rolling mills are used to roll hot or cold ferrous or non-ferrous strips, wires and even rods. Depending on the type of mill it could be used for hot or cold breakdown and finishing of bar, sheet or strip. They can also be used for finish rolling of thin gauge stock, embossing or compacting.

Q: Do I need a rolling mill?

A: Rolling is an important part of the metal forming process because it allows you to reduce the thickness of your metals and remove any variable that would cause them to look uneven. Of course, this can't be done by hand, so you'll need a reliable rolling mill that works for you and your purpose.

Q: How does a grinding mill work?

A: In modern era, they are usually powered by electricity. The grinding of solid materials occurs through mechanical forces that break up the structure by overcoming the interior bonding forces. After the grinding the state of the solid is changed: the grain size, the grain size disposition and the grain shape.

We're professional disc mill manufacturers and suppliers in China since 1989, specialized in providing high quality products and service. We warmly welcome you to buy or wholesale customized disc mill made in China here from our factory.Turbo Mill Grinding, Universal Fine Powder Pulverzier, Turbine Pulverizer
