Ribbon Mixer
Introduction
When materials are loaded into the Ribbon Mixer closed mixing barrel's square cone, the hopper's symmetrical axis and the rotational axis produce an angle. To obtain the best mixing effect, the materials of different components travel in three-dimensional space in the closed hopper, resulting in solid overturning, diffusion, and contraction.
When materials are fed into the Ribbon Mixer closed mixing barrel's square cone, an angle is formed between the hopper's symmetrical axis and the rotational axis. The materials of different components travel in three-dimensional space in the closed hopper to provide the best mixing effect, resulting in solid overturning, diffusion, and contraction.
Working Principle
When mixing, the rotating axis of the mixer deviates at an angle from the center of the mixing container. When the container rotates, the material undergoes diffusion, flow, and tangential movement, resulting in a mixed material that undergoes diffusion, contraction, flow, and tangential movement between the materials as a result of frequent and rapid rotation and flip, allowing the materials to be doped with each other by their respective states. Ascertain that the material fulfills the optimum mixing standards in a timely manner.
Structural Features
1. Composed of U-shaped container, spiral belt mixing blade and transmission parts;
2. The U-shaped long cylinder structure ensures the small resistance movement of the mixed materials (powder, semi-fluid) in the cylinder.
3. The forward and reverse rotating spirals are installed on the same horizontal axis to form a low-power and high-efficiency mixing environment. The spiral blades are generally made into double or triple layers. The outer spiral collects materials from both sides to the center, and the inner spiral The spiral transports the material from the center to both sides, which can cause the material to form more vortices in the flow. Speed up the mixing speed and improve the mixing uniformity;
4. The horizontal ribbon mixer is a new type of mixing equipment with high efficiency, high uniformity, high loading coefficient, low energy consumption, low pollution and low breakage.
5. This product has a wide range of applications and can be used to mix powder and powder, powder and liquid, especially pasty, viscous or large specific gravity materials (such as putty, real stone paint, metal powder, etc. product). It is widely used in pharmaceuticals, food, pesticides, dyes, chemicals, plastics, ceramics, coatings, putty, mortar and other fields.
