Low-Temperature Pulverizer For Probiotics

The Low-Temperature Pulverizer for Probiotics is designed to process heat-sensitive probiotic materials, particularly freeze-dried probiotic blocks, cakes, and dried probiotic materials. The main purpose is to reduce the material into a uniform powder while keeping the grinding temperature under control.
Send Inquiry
Chat Now
Product Introduction
Introduction



The Low-Temperature Pulverizer for Probiotics is designed to process heat-sensitive probiotic materials, particularly freeze-dried probiotic blocks, cakes, and dried probiotic materials. The main purpose is to reduce the material into a uniform powder while keeping the grinding temperature under control.

Probiotic products contain living microorganisms, so excessive heat generated during conventional pulverization may affect product quality and viability. Low-temperature grinding provides a more controlled processing environment and is therefore suitable for probiotic powder production.



product-800-800



Working principle:



After vacuum freeze drying, the probiotic material is typically obtained as a dry, porous block or cake. The material is fed into the pulverizer and broken down by mechanical impact, shearing, or grinding.

During operation, a cooling system helps control the temperature of the grinding chamber and material. For particularly heat-sensitive materials, liquid nitrogen cooling can be used to rapidly reduce the material temperature and minimize heat accumulation.



product-800-800



Characteristic:



The Low-Temperature Pulverizer for Probiotics is specially designed for heat-sensitive materials such as probiotic freeze-dried blocks and probiotic powder. Its main feature is effective control of temperature during the grinding process, helping reduce heat accumulation caused by high-speed mechanical pulverization. For materials with higher temperature sensitivity, a liquid nitrogen cooling system can be used to create a low-temperature grinding environment and improve grinding performance. The equipment can efficiently break brittle freeze-dried materials into fine and relatively uniform powder, while the final particle size can be adjusted according to product requirements. It can also be combined with a vibro sifter for particle classification, making it suitable for continuous powder processing. With its controlled grinding temperature, flexible particle-size adjustment, and compatibility with freeze-dried probiotic materials, the machine provides a practical solution for producing probiotic powder, pet probiotic powder, and other heat-sensitive biological powders.



product-850-726



Technical parameters



Model WF-200 WF-350 WF-450
Capacity(mm) φ200 φ350 φ450
Rotary Speed(kw) 11.25 43.25 54
Dia of Rotor Liquid nitrogen Liquid nitrogen Liquid nitrogen
Motor Power(℃) ≥-196 ≥-196 ≥-196
Output Fineness(mesh) 10-500 10-500 10-500
Feeding Granularity(kg/h) 30-100 80-500 100-800
Size of input Granules(mm) ≤8 ≤8 ≤8
Maximum Revolution Speed of Spindel(rpm) 0-6700 0-5200 0-4000
Dimensions(mm) 1700*1000*1650 2500*2000*2500 2800*2000*2700



FAQ



1. Q: What is a Low-Temperature Pulverizer for Probiotics?

A: The Low-Temperature Pulverizer for Probiotics is a grinding machine designed to reduce probiotic materials, such as freeze-dried probiotic blocks, into a uniform powder while minimizing heat generation during grinding.

For heat-sensitive probiotic products, controlling the grinding temperature is important because excessive heat may affect product stability and probiotic viability.



2. Q: Why use a low-temperature pulverizer for probiotics?

A: Probiotic materials can be sensitive to heat, moisture, and mechanical stress. Conventional high-speed grinding may generate heat during operation.

Low-temperature grinding helps control the material temperature and provides a more suitable processing environment for heat-sensitive probiotic products.


3. Q: Can the machine grind probiotic freeze-dried blocks?

A: Yes. It can be used to process probiotic freeze-dried blocks, freeze-dried cakes, and other brittle probiotic materials into powder.

A typical process is:Freeze Drying → Low-Temperature Pulverizing → Sieving → Packaging.



4. Q: Can Fangyuan Machinery customize a Low-Temperature Pulverizer for Probiotics?

A: Yes. Fangyuan Machinery can provide customized low-temperature and cryogenic pulverizing solutions according to the customer's material characteristics, production capacity, target particle size, temperature requirements, and probiotic processing process.

For a complete probiotic production line, Fangyuan Machinery can also coordinate the pulverizer with vacuum freeze dryers, vibro sifters, mixers, and other powder-processing equipment.
