Introduction To Coriander Seed Grinder

The crusher utilizes the relative operation between the movable toothed disc and the fixed toothed disc to crush the coriander seeds through the impact and friction of the toothed disc and the collision between the materials. The crushed materials can be directly discharged from the grinding chamber.

1. Toothed claw structure: It adopts double-layer toothed discs inside and outside, with toothed claws distributed on them. The extra-thick steel toothed discs combined with forged hammer heads can achieve three-stage crushing and four-stage grinding, with high crushing efficiency and the ability to grind coriander seeds more finely.

2. Self-priming design: Equipped with an automatic suction device, it generates suction force through a fan to automatically suck coriander seeds into the crushing chamber, eliminating the need for manual feeding. This saves time and effort and also prevents dust from flying.

3. Dust removal function: It is standard-equipped with a Shakron dust collector or can be combined with pulse dust collectors and other equipment. Through methods such as cyclone separation or pulse jet blowing, it effectively collects the dust generated during the crushing process, keeping the working environment clean and hygienic.

Equipped with a 7.5-kilowatt motor, it is powerful and can provide stable power support for the operation of the crusher, ensuring the high-speed rotation of the claw structure to achieve efficient crushing and meet the output demand of 100-400 kilograms per hour.

5. Performance characteristics

The production range is appropriate: With a production capacity of 100-400kg per hour, it can meet the production demands of small to medium-sized spice processing enterprises or shops.

The fineness of the crushed material is adjustable: It is equipped with screens of different mesh sizes inside. By changing the screens, the coriander seeds can be crushed to different fineness within the range of 10-120 mesh.

Wide application range: Besides coriander seeds, it can also be used to crush various spices such as Sichuan pepper, fennel, chili peppers, black pepper, as well as some grains and chemical raw materials.
